제품 상세 정보:
결제 및 배송 조건:
|
| 프레임 재질: | 금속 | 금속 종류: | 강철 |
|---|---|---|---|
| 압력 처리 목재 유형: | 열처리 | 프레임 마감: | 분말 코팅 |
| 특징: | 지탱할 수 있어 FSC인 ECO 친선 경기, 처리된 압력을 쉽게 모았습니다 | 용법: | 정원 울짱, 고속 도로 울타리, 스포츠 울타리, 농가 울타리, 형무소 담장 |
| 유형: | 격자와 게이츠, 보안용 펜스, 차도 게이츠, 울타리 접근자인 펜싱 | 서비스: | 3 차원 모델링, 견본 모형들 3D명, 지시서, 비디오의 설치합니다 |
| 패널 높이: | 2.1m,2.4m,2.9m | 패널 폭: | 2.5m,2.9m |
| 와이어 직경: | 3.85/4 밀리미터 | 열기: | 76.2*12.7mm |
| 표면 처리: | 직류 전기로 자극된 코팅되거나 핫-딥우프트 PVC | 상업 구매자: | 백화점 |
| 그림 물감: | 녹색 RAL6005, 검은 RAL9010, 브라운 RAL과 기타 | 디자인 스타일: | 산업적, 농가 |
| 이메일: | devin@industrialmetalmesh.com | 왓츠앱: | +8615369013183 |
| 강조하다: | 358 anti climb mesh fence,heavy duty clear-vu fencing,security wire mesh fence panels |
||
The name "358" comes from its specification: 3"*0.5"*8 gauge, which means approximately 76.2mm*12.7mm*4mm (mesh opening* wire diameter).358 Anti Climb Security Fence is extremely difficult to penetrate through, because the small mesh aperture is effectively finger proof, and extremely hard to attack by using conventional hand tools.
| Mesh Size(mm) | Height(mm) | Width(mm) | Wire Dia(mm) | Post Height(mm) | Surface Treatment |
| 76.2*12.7 75*12.5 75*13 |
2100 | 2515/2750/3000 | 2.0-5.0 | 2700 | Galvanized Powder Coated PVC coated |
| 2200 | 2515/2750/3000 | 2800 | |||
| 2400 | 2515/2750/3000 | 3000 | |||
| 2700 | 2200/2300 | 3700 | |||
| 3000 | 2200/2300 | 4000 | |||
| 3600 | 2200/2300 | 4800 | |||
| 4000 | 2200/2300 | 5200 |
| Horizontal Wire and Vertical Wire With V Fold 358 Security Fence | ||||||
| Mesh Opening | Wire Thickness | Panel Width | Panel Height | Number of Folds | Post Type | |
|
76.2*12.7mm (3''*0.5'') |
3.0mm or |
2.0m or 2.50m |
1830mm | 3 | Square Post(SHS) 50X50x1.5/2.0mm 60x60x1.5/2.0mm 80x80x1.5/2.0mm |
Rectangular Post(RHS) 40x60x1.5/2.0mm 40x80x1.5/2.0mm 60x80x1.5/2.0mm 80x100x1.5/2.0mm |
| 1930mm | 3 | |||||
| 2030mm | 4 | |||||
| 2230mm | 4 | |||||
| 2430mm | 4 | |||||
| Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating | ||||||
| Color: RAL 6005 green, RAL 7016 gray, RAL 9005 black,All RAL color can be customized. | ||||||
| Note: The fence can be customized according to your required if above specification is not satisfied with you | ||||||
| Horizontal Wire and Vertical Wire 358 Security Fence | |||||
| Mesh Opening | Wire Diameter | Height of Fence | Width of Fence | Post Type | |
| 12.7x76.2mm (0.5'' x 3'') |
3/3.5/4mm | 1.2-2.5m | 2.0-3.1m | Square Post(SHS) 60x60x2.0/2.5/3.0mm 80x80x2.0/2.5/3.0mm |
40x60x2.0/2.5/3.0mm 40x80x2.0/2.5/3.0mm 60x80x2.0/2.5/3.0mm |
| Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating | |||||
| Color: RAL 6005 green, RAL 7016 gray, All RAL color can be customized. | |||||
| Note: The fence can be customized according to your required if above specification is not satisfied with you | |||||
