| 구멍 모양: | 사각형, 사각형, 긴 구멍 | 와이어 게이지: | 0.5mm-14mm,2.0-4.0mm,BWG#12--#26,0.3-2.5mm,0.3mm-8.0mm |
|---|---|---|---|
| 애플리케이션: | 건설 철망, 울타리 메쉬, 건물, 교량, 정원 울타리 | 유형: | 용접 그물, 전선 메쉬, 패널 또는 명부 |
| 구멍: | 1/2, 1/4 -6, 1 Ｘ 2 " ect | 표면 처리: | 코팅된 뜨거운 침지된 직류 전기로 자극된, pvc, 코팅된 활성화된 / pvc, 코팅된 파우더 |
| 너비: | 2.2m,1.2m에 대한 0.5-2m,0.5-1.8m,300mm-2500mm,0.5m | 길이: | 30m, 50m, 10m, 5m, 25m |
| 용법: | 보호, 건물, 건설 | 포장: | 대량으로, 팔레트 |
| 제품명: | 용접철망, 직류 전기로 자극된 / PVC 코팅된 용접철망 | 색상: | 은, 녹색, 회색, 기타 등등 |
| 이름: | 용접철망, 스톤 새장 네트, pvc는 팔려고 내놓 철근 콘크리트 용접철망을 코팅했습니다 | 구멍 크기: | 고객 요청으로서의 5/8 " |
| 와이어 직경: | 1.0mm ~ 4.50mm | 메쉬 크기: | 50x100mm |
| 이메일: | devin@industrialmetalmesh.com | 왓츠앱: | +8615369013183 |
| 강조하다: | 1/2 inch stainless steel welded wire mesh,1.4mm SUS304 welded mesh for cages,stainless steel wire mesh for poultry |
||
Welded wire mesh panels material: black iron wire, galvanized before welding, galvanized after welding, hot-dipped galvanized welding, PVC coated, PE Coated, Powder coating. Welded wire mesh panels made from galvanized wire or black iron steel wire can also be PVC-coated or powder-coated to shield them from corrosion and rust.
Welded wire mesh panels can be used for a wide range of applications, usage as below: security cages, security fencing, metal fencing, dog fencing, animal enclosures, aviaries, bird cages, pet hutches, cat fences, pond covers or protection, garden fencing, and construction materials.
Welded wire mesh is high-quality low low-carbon steel wire welded row, and then cold plating (electroplating), hot galvanized, PVC-coated surface passivation, and plastics processing. To achieve a smooth surface, uniform mesh, strong joints, local good mechanical properties, stability, corrosion corrosion resistance.
Material:Low carbon steel wire, Stainless steel 302, 304, 304L, 316, 316L, Special materials, specifications can be customized according to customer requirements
|
Specification
|
||
|
Opening
|
Wire Diameter
|
|
|
Inch
|
metric Unit(mm)
|
|
|
1"x1"
|
25mmx25mm
|
2.5mm,2.0mm,1.8mm,1.6mm
|
|
2"x2"
|
50mmx50mm
|
2.5mm,2.0mm,1.8mm,1.6mm
|
|
2"x3"
|
50mmx70mm
|
6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm
|
|
2"x4"
|
50mmx100mm
|
6.0mm,5.0mm,4.0mm,3.0mm,2.0mm
|
|
2"x6"
|
50mmx150mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
2"x8"
|
50mmx200mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
3"x3"
|
75mmx75mm
|
6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm,1.6mm
|
|
3"x4"
|
75mmx100mm
|
6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm
|
|
4"x4"
|
100mmx100mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
5"x5"
|
125mmx125mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
6"x6"
|
150mmx150mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
Technical Note:
|
||
|
1.Standard Panel Length:0.5m-5.8m;Width:0.5m-2.4m
2.Special size available at request |
||
|
Specification of Welded Wire Mesh
|
||||
|
Opening
|
|
0.4-2M Length 5-50m |
electric galvanized after welded, hot-dipped galvanized before welded, hot-dipped galvanized after welded, PVC coated, Stainless steel wire |
|
|
In inch
|
In metric unit
|
|||
|
1/4" x 1/4"
|
6.4 x 6.4mm
|
BWG24-22
|
||
|
3/8" x 3/8"
|
10.6x 10.6mm
|
BWG22-19
|
||
|
1/2" x 1/2"
|
12.7 x 12.7mm
|
BWG23-16
|
||
|
5/8" x 5/8"
|
16x 16mm
|
BWG21-18
|
||
|
3/4" x 3/4"
|
19.1 x 19.1mm
|
BWG21-16
|
||
|
1" x 1/2"
|
25.4x 12.7mm
|
BWG21-16
|
||
|
1-1/2" x 1-1/2"
|
38 x 38mm
|
BWG19-14
|
||
|
1" x 2"
|
25.4 x 50.8mm
|
BWG16-14
|
||
|
2" x 2"
|
50.8 x 50.8mm
|
BWG15-12
|
||
|
2" x 4"
|
50.8 x 101.6mm
|
BWG15-12
|
||
|
4" x 4"
|
101.6 x 101.6mm
|
BWG15-12
|
||
|
4" x 6"
|
101.6 x 152.4mm
|
BWG15-12
|
||
|
6" x 6"
|
152.4 x 152.4mm
|
BWG15-12
|
||
|
6" x 8"
|
152.4 x 203.2mm
|
BWG14-12
|
||
|
Note: Special specifications can be made according to customers requires.
|
||||
| Welded wire mesh | |
| Material | Galvanized wire |
| surface | Surface passivation of cold plating (electroplating), hot plating, PVC, etc |
| wire diameter | 0.5-14mm |
| Aperture | 6-50mm |
| width | 1-2 meters or customized |
| length | 5-50 meters or customized |
| application | Industry, agriculture, breeding, construction, transportation, mining, etc. |
| Wire Diameter(mm) | Aperture (mm) | Width(m) | Length | |
| Inch | MM | |||
| 2.0mm-3.2mm | 1" | 25.4 | 0.914m-1.83m | commonly under 6 m per piece if loaded in 20', commonly under 12 m per piece if loaded in 40', |
| 2.0mm-4.5mm | 2" | 50.8 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 3" | 70.2 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 4" | 101.6 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 5" | 127 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 6" | 152.4 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 7" | 177.8 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 8" | 203.2 | 0.914m-2.75m | |
5. Welded wire mesh Packing:
>About welded wire mesh panel in wooden or steel pallet,50 to 500 piece per pallet.
>About welded wire mesh roll in water-proof paper.
(customer's packing is available on request.
