Rust-Proof Galvanized Steel Grating Platform Serrated Steel Grating

큰 이미지 : Rust-Proof Galvanized Steel Grating Platform Serrated Steel Grating

제품 상세 정보:

원래 장소:	중국
브랜드 이름:	Dimpled Hole Metal Sheets
모델 번호:	딤플 구멍 금속 시트

결제 및 배송 조건:

최소 주문 수량:	10개
포장 세부 사항:	팔레트
배달 시간:	15~18일
지불 조건:	향상에서 30%TT, 로딩 전에 균형
공급 능력:	1000조각

상세 제품 설명

화학 성분:	Fe, Ｃ, Si, Mn, Ｓ, Ｐ	합금 여부:	비합금
프로젝트 솔루션 역량:	그래픽 디자인, 3D 모델 디자인, 프로젝트 토탈 솔루션	애플리케이션:	별장
표면 처리:	페인트를 칠하거나 미처리하는 열침 아연 도금	그레이트 길이:	1000mm
그레이트 폭:	800mm	지탱 봉 폭 Ｘ 두께:	25x3mm
지탱 봉 형태:	평범하고 톱니 모양이 내가 타입 스타일 스틸 그레이팅을 방해합니다	크로스 바 형태:	휘어져 바 형상을 둥글게 하세요
메쉬 크기:	30x100mm	이메일:	devin@industrialmetalmesh.com
왓츠앱:	+8615369013183
강조하다:	rust-proof galvanized steel grating , serrated steel grating platform , galvanized steel grating with warranty

Rust-Proof Galvanized Steel Grating Platform Serrated Steel Grating

Serrated When the gratings are used in particularly wet environments or in places where extra non-slip properties are required, serrated bars will be an advantage. The serrated process involves carving a pattern in the bars to be serrated. This could be in either the control or filler bars or in both control and filler bars and bearing bars, depending on whether the grating needs serrated in one or both directions. Serration is available in two patterns: small serration and large serration
* Small Serration Small serration is the most commonly used serrated form, which is used for industrial walkway and staircase gratings etc. and for heavy duty ramp gratings.
* Large Serration This type of serrated is very easy to clean and therefore primarily used in industrial kitchens, canteens and in other places with high hygiene requirements and requirements of non-slip properties. Serrated bearing bars and control and filler bars.

Product Parameters (Technical Specifications)
Parameter	Specification Options	Standard / Notes
Material	Mild Carbon Steel (Q235), Stainless Steel (304, 316), Aluminum	Most common: Carbon steel with galvanizing
Bearing Bar	Flat, Serrated, I-Bar	Serrated for maximum slip resistance
Bearing Bar Thickness	3mm, 4mm, 5mm, 6mm	Custom thicknesses available
Bearing Bar Spacing	30mm, 34.3mm (1-3/16"), 40mm, 41mm	30mm spacing is standard for walkways
Cross Bar Spacing	50mm, 100mm	100mm is most common
Surface Treatment	Hot-Dip Galvanized, Painted, Powder Coated, Black (Ungalvanized)	HDG to ASTM A123 is standard for carbon steel
Panel Standard Size	1000mm x 6000mm, 1000mm x 5000mm, Custom Sizes	Can be cut to your exact dimensions
Load Classes	Standard (15A/15B), Heavy-Duty, Special Duty	According to ANSI/NAAMM MBG 531 or EN ISO 14122
Note: All specifications can be customized. Consult our engineering team for project-specific requirements.

metal walking grates introduction-- galvanized road drainage grates

Bearing bar type	Flat bar	I bar	Serrated bar
Cross bar type	Twisted bar	Round bar	flat bar
Production process	welded	Pressure locked
Surface treatment	Self-colour	Galvanized	painted
application	Platform	walkway&floor	Trench cover	Steel stair treads
	Suspended ceiling	Barrier fence

bearing bar types:
surface treatment: mill finish,hot dip galvanized,painted

Material	Carbon Steel, Stainless Steel, Aluminum
Surface treatment	Hot dipped galvanized, Spray painting, Polished and powder coated
Bearing bar type	Plain(Flat) bar, Serrated bar, I-bar, etc.
Common specification
Bearing bar pitch (mm)	Cross bar pitch (mm)	Bearing bar size (WSG_Height×Thickness_Bearing bar pitch_Cross bar pitch)
30	100	WSG_203/253/323/403/205/325/405/455/505/555_30_100
	50	WSG_203/253/323/403/205/325/405/455/505/555_30_50
40	100	WSG_203/253/323/403/205/325/405/455/505/555_40_100
	50	WSG_203/253/323/403/205/325/405/455/505/555_40_50
60	50	WSG_203/253/323/403/205/325/405/455/505/555_60_50
If you have any questions regarding the dimensions or specific specifications, please feel free to contact us immediately.

Advantages:
high strength, anti-slip, ventilation and light transmission properties.

Steel grating is widely used in the following fields:
1. Petrochemical, power and metallurgy, sewage treatment and other industrial fields.
2. Drainage systems, stairs and railings, commercial decoration and other municipal and architectural fields.
3. Bridges and tunnels, ports and ships and other transportation and marine engineering.
4. Garbage treatment plants, agricultural facilities and other environmental protection and agricultural fields.

Rust-Proof Galvanized Steel Grating Platform Serrated Steel Grating 0

Key Features

· Exceptional Strength-to-Weight Ratio:Engineered to support heavy loads while remaining relatively lightweight, reducing structural support requirements.
· Superior Safety:Serrated or plain surfaces provide excellent slip resistance, even in wet or oily conditions. The open design allows passage of light, air, and liquids, minimizing puddles and ice accumulation.
· Long-Lasting Durability:Manufactured from high-quality carbon steel or stainless steel, with optional hot-dip galvanizing, powder coating, or other finishes for outstanding corrosion resistance.
· Low Maintenance & Easy Installation:The modular design allows for quick cutting, fitting, and installation with standard tools. Its open structure prevents the accumulation of dirt, debris, and snow, minimizing cleaning needs.
· Versatile & Aesthetic:Available in various materials, surface types, and finishes to meet functional requirements and architectural aesthetics.
