제품 상세 정보:
결제 및 배송 조건:
|
| 화학 성분: | Fe, Ｃ, Si, Mn, Ｓ, Ｐ | 합금 여부: | 비합금 |
|---|---|---|---|
| 프로젝트 솔루션 역량: | 그래픽 디자인, 3D 모델 디자인, 프로젝트 토탈 솔루션 | 애플리케이션: | 별장 |
| 표면 처리: | 페인트를 칠하거나 미처리하는 열침 아연 도금 | 그레이트 길이: | 1000mm |
| 그레이트 폭: | 800mm | 지탱 봉 폭 Ｘ 두께: | 25x3mm |
| 지탱 봉 형태: | 평범하고 톱니 모양이 내가 타입 스타일 스틸 그레이팅을 방해합니다 | 크로스 바 형태: | 휘어져 바 형상을 둥글게 하세요 |
| 메쉬 크기: | 30x100mm | 이메일: | devin@industrialmetalmesh.com |
| 왓츠앱: | +8615369013183 | ||
| 강조하다: | painted welded steel grating,serrated steel grating,galvanized steel grating with warranty |
||
Painted Welded Steel Grating with Serrated Surface
Grating, also called steel grating or steel bar grating, refers to the steel bar grating made of mild carbon steel through surface treatment.
Mild carbon steel provides an economical, high strength for uses in most industrial and commercial applications.
Steel grating is available in various material, such as stainless steel, aluminum, and galvanized steel.
| Specifications of steel gratings | |
| Bearing bar | 20x5,25x3,25x4, 25x5,30x3,30x4,30x5,32x3,32x5,40x5,50...75x8mm, etc. |
| Bearing bar depth | 25,30,30.16,32.5,34.3,40,50,60,62,65mm, etc. |
| Cross bar | 5x5, 6x6,8x8mm (twisted bar or round bar) |
| Cross bar spacing | 40, 50,60,65,76,100,101.6,120,130mm or as customers' requirement. |
| Flat bar type | Plain, Serrated (tooth-like), l bar (l section) |
| Surface treatment | Untreated |
| Hot dip galvanized | |
| Cold dip galvanized | |
| PVC coated | |
| Powder coated | |
| Note: 1.Special sizes avaliable at request. 2.Packing:in plastic in rolls. Custom packing available at request. |
|
metal walking grates introduction-- galvanized road drainage grates
| Bearing bar type | Flat bar | I bar | Serrated bar | |
| Cross bar type | Twisted bar | Round bar | flat bar | |
| Production process | welded | Pressure locked | ||
| Surface treatment | Self-colour | Galvanized | painted | |
| application | Platform | walkway&floor | Trench cover | Steel stair treads |
| Suspended ceiling | Barrier fence |
bearing bar types:
surface treatment: mill finish,hot dip galvanized,painted
steel grating standard-- galvanized road drainage grates
| Steel Grating Standard | |||
| Steel Grating Standard | Steel Standard | Galvanizing Standard | |
| China Standard | YB/T 4001.1-2007 | GB700-88 | GB/T13912-2002 |
| USA Standard | ANSI/NAAMM (MBG531) | ASTM (A36) | ASTM (A123) |
| U.K. Standard | BS4592 | BS4360 (43A) | BS729 |
| Australia Standard | AS1657 | AS3679 | AS1650 |
| Deutsche Standard | DIN24537 | DIN17100-80 | DIN50976 |
