제품 상세 정보:
결제 및 배송 조건:
|
| 재료: | 스테인레스 스틸 와이어, 316, 304, 일반 강철 아연 도금 | 기술: | 용접 메쉬 |
|---|---|---|---|
| 애플리케이션: | 스크린, 보호메쉬 | 구멍 모양: | 정사각형 구멍, 직사각형 구멍 |
| 정상적 블레이드형: | BTO-22, BTO-30, CBT-60, CBT-65 | 이메일: | devin@industrialmetalmesh.com |
| 왓츠앱: | +8615369013183 | ||
| 강조하다: | high security razor wire mesh,anti-climb welded razor wire,concertina razor wire with warranty |
||
|
Outside Diameter
|
No. of Loops
|
Standard Length per Coil
|
Razor Type
|
Notes
|
|
450mm
|
33
|
7M-8M
|
CBT-60, 65
|
Single Coil
|
|
500mm
|
56
|
12M-13M
|
CBT-60, 65
|
Single Coil
|
|
700mm
|
56
|
13M-14M
|
CBT-60, 65
|
Single Coil
|
|
960mm
|
56
|
14M-15M
|
CBT-60, 65
|
Single Coil
|
|
450mm
|
56
|
8M-9M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
500mm
|
56
|
9M-10M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
600mm
|
56
|
10M-11M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
600mm
|
56
|
8M-10M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
700mm
|
56
|
10M-12M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
800mm
|
56
|
11M-13M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
900mm
|
56
|
12M-14M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
960mm
|
56
|
13M-15M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
980mm
|
56
|
14M-16M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
Application of concertina razor barbed wire
Razor Barbed Wire is widely used in airport , prison, government, bank, and also in living wall, personal house, villatic wall, window, autobahn, railway and border of the fence.
Packing of concertina razor barbed wire
compression rolls, water-proof paper inside, woven bag outside or in carton
Weave characteristics of concertina razor barbed wire
twist and weave, fastness ,beautiful; galvanizing after weaving, galvanizing before weaving. It is divided to electrical galvanized ,hot - dipped galvanized, plas-tic coating, stainless steel, etc.
Fetures of razor wire:
High reliability:Concertina Razor Wire also called Razor Wire.it the normal type of Razor wire you see around prisons and high security establishments. As an effective and economical security barrier, with its high security function, Concertina Razor Wire can prevent most of the intruders for it is hard and dangerous to broken.
Advantages of concertina razor barbed wire
Razor barbed wire mesh is a new kind of protective fencing with such advantages as beautiful appearance,economical cost and practicality.
| Hole shape | Mesh width | Suited blade specifications |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
